Gravity Conveyor Roller with Semi-Precision Brearing
PVC Gravity Conveyor Roller
Gravity Conveyor Roller with Steel Bearing Housing
Gravity Conveyor Roller with Polymer Bearing Housing
PVC Gravity Conveyor Roller
- Polymer ball bearing
- PVC tube ,with good chemical stability
- Very light and smoothly running, suitable for light duty load
Description：
- Very light, smooth running. Suitable for light duty conveying.
- Utilizes polymer ball bearings. The inner/outer flange of the bearing is made of POM. The ball is made of stainless steel.
- PVC tube with good chemical stability.
- PVC tube with good chemical stability.Higher noise levels compared with other series rollers.
- Temperature range: -5℃ ~ +40℃.
- Humidity range: 30-90% RH (non-condensation).
Please contact us if humidity out of this scope.
| D | T | Shaft | Tube PVC |
|---|---|---|---|
| Φ20 | 01.01 | Φ6 | √ |
| Φ25 | 01.08 | Φ8 | √ |
| Φ30 | 01.08 | Φ8 | √ |
| Φ38 | 02.00 | Φ8/10 | √ |
| Φ50 | 02.05 | Φ8/10/12 | √ |
